In public areas such as malls, warehouses, and corridors, emergency luminaires must endure impacts, humidity, and frequent handling. Voyager serves as an excellent Public area emergency light and Retail store emergency light, with impactresistant blade design and 30m visibility. Guard Fit, with IP65 protection and modular slim profile, works as a flexible Fit type emergency light for surface or recessed mounting, and can be configured as a Bulkhead type emergency light for wall installation. For harsh racking areas, we offer a dedicated Warehouse bulkhead emergency light with reinforced shell.
Key Points
Voyager Emergency Blade Exit Sign: PC housing with PET pictogram, 3mm or 8mm blade thickness, 30m visibility. LiFePO₄ 3.2V 1800mAh battery, selftest, maintained/nonmaintained. Input 5W, emergency 1W, charge ≤24h, discharge ≥3h, 6500K, CRI>80, IP20.
Guard Fit Emergency Downlight: IP65, modular ultraslim, interchangeable round/elliptical lens. LiFePO₄ 3.2V battery (1500/1800/3400mAh), input 3W, emergency 1/1.3/2.2W, 160320lm, 6500K, charge ≤24h, discharge ≥3h, manual/selftest/DALI2, Class II, 045°C, 5year warranty.
A Bulkhead type emergency light must withstand bumps, dust, and moisture. Voyager’s PC housing resists impact and UV; the blade can be chosen in 3mm or 8mm thickness for extra strength. Guard Fit’s IP65 rating keeps out dust and water jets, while its LiFePO₄ battery outlasts conventional NiCd cells. Both use mechanical fixing — screws, spring clips, or brackets — so joints never degrade like adhesive. As a Public area emergency light or Retail store emergency light, they maintain structural integrity over years. The Warehouse bulkhead emergency light variant features an even tougher housing and IP65 for extreme conditions.
Voyager is ideal as a Retail store emergency light exit sign, wallmounted above doors or along corridors; its 30m visibility aids crowd guidance. Guard Fit works as a Fit type emergency light, recessed or surfacemounted, providing daily illumination and automatic emergency backup — perfect for retail, offices, and hospital corridors. When configured as a Bulkhead type emergency light, Guard Fit handles damp stairwells. For heavyduty areas, the Warehouse bulkhead emergency light offers an impactproof shell and IP65, fixed with screws.
Install: Voyager — drill holes, fix bracket with screws and anchors, attach the sign and lock. Guard Fit recessed — cut opening, push until spring clips lock; surface version — screw base to ceiling. Manuals only state “screw fix,” “spring clip lock,” “bracket lock.” Maintenance: Test quarterly via button; replace battery every 3 years. Mechanical fixing allows fixture removal without damage — battery compartments also use screwsealed covers.
Conclusion
IMIGY’s Voyager Emergency Blade Exit Sign and Guard Fit Emergency Downlight deliver durable emergency lighting with rugged housing, longlife LiFePO₄ batteries, and 100% mechanical fixing — no “seamless.” Whether you need a Public area emergency light, Retail store emergency light, Bulkhead type emergency light, Warehouse bulkhead emergency light, or a versatile Fit type emergency light, IMIGY provides products built to last. All fixtures are mechanically locked with screws, brackets, or spring clips. Choose IMIGY: emergency lighting as sturdy as your safety demands.
Further product and certification details are available at https://www.imigyled.com/.
FAQ
Q: How to choose Voyager blade thickness? A: 3mm for standard use; 8mm for higher impact resistance. Panels are replaceable; installation is mechanical.
Q: Is Guard Fit’s battery reliable in cold? A: LiFePO₄ operates 045°C with good lowtemperature performance. Fixing is springclip mechanical.
Q: How is Warehouse bulkhead emergency light different? A: Tougher housing, IP65, designed for dusty/wet warehouse conditions. Fixing is screw mechanical — no “seamless.”
