LED Down Lights

Explorer Downlight- Explorer Downlight B

D15-B LED downlight in perfect combination of diffuser and reflector, to provide high lighting efficiency as well as lower glare.comfortable lighting and humanization design, without compromising on lighting performance ( color rendering and color uniformity),complete size from 4 inch to 10 inch.
10W 1100lm 110lm/W CRI>80 80°
Code D15100-BM-TWI
Power 10W
Input 220-240Vac 50/60Hz
Color Temp 2700K~6500K
Lumen@4000K 1000-1100lm
Cutout(mm) φ90-102mm
IP Rating 64
IK Rating 06
CRI >80
Beam Angle 80°
Driver Outside isolated driver
Code D15150-BM-TWI
Power 18/25W
Input 220-240Vac 50/60Hz
Color Temp 2700K~6500K
Lumen@4000K 2100-2300lm/2800-3000lm
Cutout(mm) φ145-155mm
IP Rating 64
IK Rating 06
CRI >80
Beam Angle 80°
Driver Outside isolated driver
Code D15180-BM-TWI
Power 28W
Input 220-240Vac 50/60Hz
Color Temp 2700K~6500K
Lumen@4000K 3000-3360lm
Cutout(mm) φ165-180mm
IP Rating 64
IK Rating 06
CRI >80
Beam Angle 80°
Driver Outside isolated driver
Code D15205-BM-TWI
Power 28/35W
Input 220-240Vac 50/60Hz
Color Temp 2700K~6500K
Lumen@4000K 3000-3360lm/3500-4025lm
Cutout(mm) φ195-210mm
IP Rating 64
IK Rating 06
CRI >80
Beam Angle 80°
Driver Outside isolated driver
Code D15250-BM-TWI
Power 40W/50W
Input 220-240Vac 50/60Hz
Color Temp 2700K~6500K
Lumen@4000K 4200-4800lm/5000-5750lm
Cutout(mm) φ240*255mm
IP Rating 64
IK Rating 06
CRI >80
Beam Angle 80°
Driver Outside isolated driver
  Various ring accessories for options: Round/Square/Glass module.
  Aluminum Spinning housing provides excellent heat dissipation performance.
  High lumen efficiency up to 120lm/w.
  Interchangeable reflector in white, matt silver, bright silver and black color.
  External flicker free Casambi driver.4 ", 6 ", 8 ".
  Programming via intuitive Casambi app.
